Zwaardvis class Submarine

zwaardvis class attack submarine ssk royal netherlands navy koninklijke marine 17x

04/25

Units:

S 806 HNLMS Zwaardvis
S 807 HNLMS Tijgerhaai

Specifications:

Type: Diesel-electric Attack Submarine

Displacement: 2,408 t surfaced / 2,640 t submerged
Length: 66.9 meters (219 ft 6 in)
Beam: 8.4 m (27 ft 7 in)
Draft: 7.1 m (23 ft 4 in)
Speed: 13 knots (24 km/h; 15 mph) surfaced / 20 knots (37 km/h; 23 mph) submerged
Range: 18,500 km (10,000 nmi) at 9 kn (17 km/h; 10 mph)
Test depth: >220 m (720 ft)
Complement: 67

Propulsion:
Diesel-Electric
3 x Werkspoor diesel engines 4,200 hp (3,100 kW), each
1 x HOLEC electric motor 5,100 hp (3,800 kW)
2 x 196-cell batteries
1 shaft, 1 propeller

Systems:
Type 1001 radar
Thomson Sintra TSM 2272 Eledone Octopus bow-mounted sonar
Type 2026 towed array sonar
DUUX 5 Fenelon passive acoustic rangefinding and search sonar

Armament:
6 x 21-inch (533 mm) torpedo tubes
for up to 20
Mark 8 torpedoes > later Mk.37 torpedoes > later Mk.48 Mod.7 torpedoes

The Zwaardvis class ("Swordfish") submarines were designed by the Royal Netherlands Navy. In comparison to the three-cylinder design of the Dolfijn-class submarines, the Zwaardvis class submarines are based on one cylinder. The reasons why the Royal Netherlands Navy and its partners choose for this design was because it resulted in more space within the submarines, which would give the crew a more spacious accommodation and make it also easier to set up machines within the submarines. The hydraulic system of the boats included three pumps and three accumulators. They were equipped with controls sliders made by Rexroth.

In addition, the submarines are based on the U.S. Navy Barbel class with the teardrop hull design, which results in the submarines producing less noise. The propulsion of the Zwaardvis class is also different from the Dolfijn class submarines, for example, it has a single propeller instead of the two propellers the latter has. Furthermore, it has more diesel engines, the batteries require less charging time, it can launch missiles and torpedoes from greater depths, the diving depth has increased substantially, and lastly it can stay longer submerged. The introduction of the Zwaardvis class submarines also led to the Royal Netherlands Navy using the Mk.37 torpedoes. In 1988 the Mark 37 torpedoes for the Zwaardvis class submarines were replaced with the newer Mk.48 torpedoes.
