Impetuoso class Destroyer Italian Navy Marina Militare

Italian Navy / Marina Militare Italiana
Impetuoso class Destroyer

impetuoso class destroyer italian navy marina militare indomito d-558 d-559 nave 03x

10/22

Ships:

D 558 ITS Impetuoso
D 559 ITS Indomito

Specifications:

Displacement: 2775 tons (standard) / 3810 tons (full load)
Length: 127.6 meters (418 feet 8 in)
Beam: 13.2 meters (43 ft 4 in)
Draft: 4.5 meters (14 ft 9 in)
Speed: 34 knots (63 km/h)
Range: 3000 NMI (5600 km) at 16 knots (30 km/h)
Complement: 315

Propulsion:
2 x geared steam turbines
4 x Foster Wheeler boilers
65000 hp / 48000 kW
2 shafts / 2 propellers

Armament:
2 x 5”/38 caliber (127mm) twin guns
2 x Bofors 40mm/L60 quad AA guns
4 x Bofors 40mm/L60 twin AA guns
1 x K-113 12“(305mm) Menon ASW mortar
2 x 21” (533mm) torpedo tubes for heavy-weight torpedoes (earlier)
2 x Mk.32 12.75” (324mm) triple torpedo tubes for Mk.44 torpedoes (later)

Aviation:
none

Systems:
SPS-6 air search radar
SG-6B surface search radar
SPG-25 fire control radar
SPG-34 fire control radar
SQS-11 > later SQS-4 sonar

The Impetuoso class were the first post-World War II destroyers built for the Italian Navy. The two ships were ordered in February 1950 and entered service in 1958.

The Impetuoso class hull design was based on the uncompleted World War II Comandanti Medaglie d'Oro-class destroyer. The class has a length of 127.6 m (419 ft) with length between perpendiculars of 123.4 m (405 ft), a beam of 13.2 m (43 ft), with a draught of 4.5 m (15 ft), and their displacement were 2,775 long tons (2,820 t) standard and 3,810 long tons (3,870 t) at full load. The ships was powered by two-shaft geared steam turbines with four Foster Wheeler boilers, with total power output of 65,000 shaft horsepower (48 MW). Impetuoso class has a maximum speed of 34 knots (63 km/h), with range of 3,000 nautical miles (5,600 km) while cruising at 16 knots (30 km/h). The ships has a complement of 315 personnel.

The class were armed with four 5-inch (127 mm)/38 caliber guns in two twin-gun turrets, 16 Bofors 40 mm/60 guns consisted of two quad-mounts and four twin-mounts, and one 305 mm Menon anti-submarine mortar. They were also armed with two fixed 533-millimetre (21 in) torpedo tubes, which was later replaced by two 12.75-inch (324 mm) triple-tubes with Mark 44 torpedoes. There was a proposed modernization program in the late 1960s for the ships to be rearmed with a single lightweight 5"/54 caliber Mark 45 gun forward and RIM-24 Tartar surface-to-air missile launcher in the aft.

The ships electronics and sensors consisted of SPS-6 air-search radar, SG-6B surface-search radar, SPG-25 and SPG-34 fire control radar, and SQS-11 search sonar, which was later replaced with SQS-4 sonar. As of 1980, Impetuoso was equipped with WLR-1 electronic support measure system with noise jammer, while Indomito appears to be not equipped with any electronic warfare system.

source: wikipedia

class images
for more images go to the individual ship-site

impetuoso class destroyer italian navy marina militare indomito d-558 d-559 nave 04c

D 558 ITS Impetuoso

impetuoso class destroyer italian navy marina militare indomito d-558 d-559 nave 02c

D 559 ITS Indomito

impetuoso class destroyer italian navy marina militare indomito d-558 d-559 nave 07c

impetuoso class destroyer italian navy marina militare indomito d-558 d-559 nave 09c
